MS 180, MS 180 C

Technical Specifications

All compatible products are listed below.

CHAINSAW CHAINS  SPECIFICATION PDF


Engine displacement: 31.8 cc, Power output: 1.5 kW / 2.0 hp, Engine type: 2-stroke

Weight without bar and chain: 4.1 kg / 9.0 lbs

Cutting Equipment

Recommended bar length: 30–40 cm / 12–16 inch, Chain type: STIHL Oilomatic 3/8 P Picco Micro, Chain pitch: 3/8 P, Guide bar gauge: 1.3 mm / .050 inch

Fuel and Oil System

Fuel tank capacity: 0.25 L / 8.5 oz, Oil tank capacity: 0.145 L / 4.9 oz, Automatic chain lubrication: Ematic system

Performance and Comfort

Anti-vibration system: Yes, Sound pressure level: approximately 100 dB A, Sound power level: approximately 112 dB A, Vibration level left/right: 6.6 / 7.8 m/s²
